256ch Dahua NVR 24 Hot-swap HDDs LCD Super cctv Network Video Recorder NVR724D-256

FOB Reference Price:Get Latest Price
  • 1 - 4 Pieces
    $3,868.00
  • >=5 Pieces
    $3,735.00
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Dahua
Model Number:
NVR724D-256
Video input:
256 Channels
HDD:
24 SATA HDD, up to 8TB
Recording Resolution:
12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P etc.
Network Interface:
4RJ-45
VGA/HDMI output:
1 VGA/2 HDMI
Size:
4U chassis
Power Supply:
AC100V ~ 240V, 50 ~ 60 Hz
Alarm In:
4-ch
Alarm out:
4-ch
Supply Ability
Supply Ability:
1000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Weight: about 38kg (83.8 lb)
Measurement: 482.6mm * 570.12mm * 175mm (19 * 22.4 * 6.9 )
Port
ShangHai
Lead Time :
Shipped in 7 days after payment
Top





Product Description









Model



NVR724D-256 :  512Mbps, Max 12MP, 20ch 1080P decoding, H.264, 1 VGA/2 HDMI(10HDMI optional), 4 RJ45(1000M), 4 USB(2USB3.0), 1/1ch audio in/out, 24 HDD(6TB each), 1 eSATA, 4/4 alarm in/out, fisheye dewarp, IVS(optional), face detection, RAID0/1/5/6/10/50/ 60, N+M, ANPR, thermal, 2 Mini SAS



Features

> Intel Processor
> Max 256 IP Camera Inputs
> Max 512Mbps Incoming Bandwidth
> 24 Hot-swap HDDs
> Supports RAID 0/1/5/6/10/50/60
> iSCSI and Mini SAS for Expanded Storage Space
> Optional HDMI Output Extension Board with 8 HDMI
> Smart Tracking and Intelligent Video
> 7-inch HD LCD Monitor



Specification



NVR724D-256

System

Main Processor

Intel Core i7 Processor

Operating System

Embedded LINUX

Audio and Video

IP Camera Input

256 Channel

Two-way Talk

1 Channel Input, 1 Channel Output, RCA

Display

Interface

2 HDMI (Different Source), 1 VGA

8 HDMI (Optional)

Resolution

1920 × 1080 , 1280 × 1024,

1280 × 720 , 1024 × 768

Multi-screen Display

1st Screen: 1/4/8/9/16/25/36/64

2nd Screen: 1/4/8/9/16

OSD

Camera title, Time, Video loss, Camera lock,

Motion detection, Recording

Recording

Compression

H.264/MJPEG

Resolution

12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P etc.

Record Rate

512Mbps

Bit Rate

16Kbps ~ 20Mbps Per Channel

Record Mode

Manual, Schedule (Regular, MD (Motion Detection), Alarm, IVS), Holiday, Stop

Record Interval

1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec

Video Detection and Alarm

Trigger Events

Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips

Video Detection

Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering

Alarm input

4 Channel, Low Level Effective, Green Terminal Interface

Relay Output

4 Channel, NO/NC Programmable, Green Terminal Interface

Tracking Trigger Event

Zoom, Tracking, Recording, Preset, Snapshot, Alarm, etc.

Playback and Backup

Playback

128 Mbps in Raid 5 Mode;

64 Mbps in single HDD Mode

Search Mode

Time /Date, Alarm, MD and Exact Search (accurate to second)

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom

Backup Mode

USB Device/Network

Third-party Support

Third-party Support

Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more

Network

Interface

4 RJ-45 Ports (10/100/1000Mbps)

Ethernet Port

4 Ethernet Ports Joint Working or 4 Independent 1000Mbps Ethernet Ports

PoE

N/A

Network Function

HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.)

Optical Fiber Interface

2 Giga Optical Fiber Interface (optional)

Max. User Access

128 users

Smart Phone

iPhone, iPad, Android

Interoperability

ONVIF 2.4, CGI Conformant

Storage

Internal HDD

24 SATA III Ports, Up to 8 TB capacity for each HDD

HDD Mode

Single, Raid 0/1/5/6/10/50/60(Enterprise-level HDDs are recommended), Support Global HDD Hot-spare

eSATA

1 eSATA Port (Please contact technical engineer to confirm the compatible device)

SAS

2 Mini SAS Port, for Storage Expansion

Auxiliary Interface

Front Cover

Support Hot-swap, 7-inch HD LCD (1920 × 1080, 1280 × 1024, 1024 × 768)

USB

4 USB Ports (2 USB 2.0 , 2 USB 3.0 )

RS232

1 Port, for PC Communication and Keyboard

RS485

1 Port, for PTZ Control

Electrical

Power Supply

AC100V ~ 240V, 50 ~ 60 Hz

Power Consumption

<200W (Without HDD)

Environmental

Operating Conditions

-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa

Storage Conditions

-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH

Construction

Dimensions

4U, 482.6mm x 570.12mm x 175mm (19" x 22.4" x 6.9")

Net Weight

25kg (55.1 lb) (without HDD)

Gross Weight

38kg (83.8 lb)

Installation

Rack-mounted

Certifications

CE

EN55022, EN55024, EN50130-4, EN60950-1

FCC

Part 15 Subpart B, ANSI C63.4-2014

UL

UL 60950-1 and CAN/CSA C22.2 No.60950-1

Accessories









Dimensions(mm)









Free Software

Free Software (Smart PSS):

Mobile App (iDMSS, gDMSS):



Packaging & Shipping

Packaging:



Shipping:

The common adopted Shipping methods including: DHL, FedEx, TNT, UPS, EMS, buik order By Air, By Sea

We can calculate the cost based on your quantity and choose a most quick and economic way for you.
We will send you tracking number before shipping.





Our Services

Payment Way:
T/T, Paypal, West Union, MoneyGram.

Delivery Time:
Goods in Stock needs 2-5 working days, not in stock and for bulk order needs 7-20 working days.

OEM Service:
We could offer OEM and ODM services for our clients.

Quality Warranty:
2 years hardware warranty, whole life technical service for continue cooperating customers.





Company Information

Hangzhou Savgood Technology Co., Ltd, a fast growing enterprise in China who specialize in Security industry, have a professional consultative selling team, everyone in the team owned at least of six years' experiences in the line of security and protection industry.



Company:



Location:





FAQ

1. What products do you deal with?

We mainly deal with IP Solutions including IP Cameras, NVRs, POE Switches, also HDCVI, AHD and some Analog Products. We developed our professional PC-Based NVR software 100% in house, which is stable and unique in the market, it could manage multi-brands IP cameras.



2. The products you provided are original?

We only provide 100% original products which are all directly from Hikvision and Dahua head factories in Hangzhou City. NO FAKE VERSION. BUT OEM Service is acceptable.



3. Are OEM products same features as original?
OEM products have all the same features as original, just with different model number, OEM NVR has different front panel.



4. Do you supply PC-baed NVR/CMS software?
Yes, all ip cameras and NVRs come with FREE NVR/CMS software.



5. Do your cameras and NVRs support Mobile viewing?
Yes, all ip cameras and NVRs support mobile APP(Android and IOS), you can see videos by phone freely.
